Key Features of the Air Manager
EPA filter: Removes up to 95% of UFPs
Controlled extraction: Inside-out airflow optimised for filtering and print quality
Enhanced safety: Physical barrier prevents reaching inside the printer
Optimised for your application: Detects material being used and adjusts airflow
Easy setup: Printer detects when the Air Manager is connected
Smart monitoring: Printer tracks filter usage and prompts replacement
Properties
Filter technology EPA filter
Fan technology Air extraction by low-noise brushless fan
Air refresh rate 1 - 50 m3/h (35 m3/h nominal rate for most materials at 23°C)
Filter efficiency Up to 95%
Filter replacement Recommended every 1,500 print hours (approx. 1 year)
Operating sound < 51 dBA (including Ultimaker S5)
Connection (data and power) UMB connection (included)
Compatible 3D printers Ultimaker S5
Compatible materials Optimised for Ultimaker PLA, Tough PLA, ABS, Nylon, CPE, CPE+, PC, PP,
TPU 95A, PVA, Breakaway (Also supports third-party materials)
Physical dimensions Dimensions 490 x 503 x 350 mm
Dimensions (including Ultimaker S5) 490 x 503 x 967 mm
Net weight 3.6 kg
Software Supplied software Ultimaker Cura, our free print preparation software
Ultimaker Connect, our free printer management solution
Ultimaker Cloud, enables remote printing
Warranty period 12 months
Key Features of the Material Station
Fast and easy loading: Front-facing bay for up to six materials reduces loading time to a few seconds
Uninterrupted printing: Sensors detect when one material spool ends and automatically loads the next
Humidity control: Intelligent atmospheric management keeps relative humidity below 40%
Easy setup and monitoring: NFC material auto- recognition and seamless integration with Ultimaker software
Composite materials compatible: Print parts with high strength and unique properties
Limitless configurations: Keep your most-used materials ready to print when you need – Ultimaker and third-party filaments
Properties
Filament diameter 2.85 mm
Material spool dimensions Width: 50 - 70 mm
Diameter: 197 - 203 mm
Core diameter: > 98 mm
Material capacity 6 spools
Material recognition Auto-recognition enabled with NFC scanner
Feeder type Dual-geared, abrasion-resistant
Data connection UMB connection (included)
Power input 85 - 264 VAC, max. 125 W
Power output Max. 10A (for Ultimaker S5)
Compatible 3D printers Ultimaker S5
Compatible materials Optimised for Ultimaker PLA, Tough PLA, ABS, Nylon, CPE, CPE+, PC, PP,
TPU 95A, PVA, Breakaway (Also supports third-party materials)
Physical dimensions Dimensions 491 x 438 x 400 mm (19.3 x 17.2 x 15.7 in)
Net weight 17.7 kg
Software Supplied software Ultimaker Cura, our free print preparation software
Ultimaker Connect, our free printer management solution
Ultimaker Cloud, enables remote printing
Warranty period 12 months
